Welding torch cleaner

Portable torch cleaner F-350/F-500
- The torch cleaner that can be used anywhere

Feature of F-350/F-500 auto torch cleaner：
One-press start, one-station for wire cut, torch
cleaning and oil spray.
Firm and reliable structure makes the product durable
Patented technology, all-in-one equipment.
(wire cut, torch cleaning and oil spray)
Trouble-free connection with the output signal of robot
Welder.
Economical, portable. The increase of service life of
quick-ware welding part brings a lower production cost
Applicable to both users of normal gas shielded welder
and robot welder station.

Specification of F-350/F-500 auto torch cleaner：
Overall size：360MM X 360MM X 300MM (length x width x height)
Total cleaning time: 14 seconds. Weight: 18kg
Diameter of wire: 1.6mm MAX for solid wire and 3.2mm MAX for
flux-cored wire
Voltage of start signal to robot welder: DC 24V
Voltage of torch cleaner: AC220V, working air pressure of torch cleaner: 0.4MPA-0.8MPA
Ejection system of splash proof: 1000ML extra large container of atomized lubricator.
